PA50ADLD Sentinel Deluxe Aeration System – 1/4 HP Kit with NO tubing

Description

PA50ADLD Sentinel Deluxe Aeration System – 1/4 HP Kit with NO tubing

Sentinel Deluxe Aeration Systems are designed for convenience and reliability. Each package includes air compressor, valved outlet assembly, pressure gauge and pressure relief valve already installed in our deluxe locking cabinet complete with a cooling fan and a electrical box/outlet already mounted and ready for your incoming power line. Simply set cabinet in desired location, install the air diffusers and connect the tubing!

PA50ADLD features:

1/4 hp Stratus RV33 Rotary Vane compressor
Two valve manifold with pressure relief
Valved outlet with heat reducing hose and 1/2″ connections
Kit does not include diffusers or tubing – select tubing and diffusers that best fit the application
Approximately 2.2 cfm of air flow per diffuser
Typical operation cost of $1.31 per 24 hours at .09¢ per kWh, actual cost may vary

Aeration Kit for Ponds up to 2 acres
1 Year Warranty on Compressor
5 Year Warranty on Cabinet

Specifications:

Tubing	None Included
Horsepower	1/4 HP
Voltage	115v (add 2 behind part # for 230v)
Amps	5.0/2.5 amps
Maximum Air Flow	4.5 cfm
Maximum Depth	18′
Weight	84
In Aeration Acres	Up to 2 acres
